SHOP DRAWER 2015

  • Automatic shop drawing program which needs only an excel sheet containing the element dimensions and reinforcement details.
  • Working on AutoCAD to produce the shop drawings automatically as normal AutoCAD drawings.
  • Complete drawings with plans, sections and elevations.
  • Complete bar bending schedules on AutoCAD or Excel.
  • Beams shop drawing.
  • Columns shop drawing.
  • Footings shop drawing.
  • Windows XP, Windows 7 or Windows 8.
  • AutoCAD 2013 or later.
  • Microsoft Excel 2010 or later.
  • 50 MB free disk space.
Coming Soon.
Online purchase is coming soon.
